2200 / F2200 Narrow Head Surface Vertical Rod Devices (SVR)

ANSI Grade 1 Heavy Duty

Specifications

Klacci 2200 / F2200 Narrow Head Surface Vertical Rod Exit Devices (SVR)

Applications		Offices, schools, banks, assisted living facilities and other institutions or commercial buildings.
Stile		Minimum width 2″ (51mm).
Certification / Compliance		Panic devices UL/cUL listed for UL305 and ANSI/BHMA A156.3-2014 Grade 1 Panic Hardware. UL/cUL Fire rated for 3-hour Fire Exit Hardware, conforms to UL10C and UBC7-2. Also complies with NFPA 80 Fire doors and windows. Exit devices, levers, trims and pulls comply with American Disability Act (ADA) and NFPA 101 life safety code.
Doors & Preparations		For new or retrofit installation into other manufacturers’ devices. For maximum door opening applications and listings for fire exit devices.
– Mullion
– Door Thickness		1-3/4″ (45mm) ~ 2-1/4″ (57mm). Consult factory for other door thickness.
– Door Wide		3′ (914mm)(standard) ~ 4′ (1219mm).
– Door High	(Panic)	7′ (2134mm)(standard) ~ 10′ (3048mm).
	(Fire)	7′ (2134mm)(standard) ~ 10′ (3048mm).
– Device Centerline from Finished Floor		39-5/8″ (1006mm).
– Door Undercut		1/4″ (6mm).
Center Case		Heavy wrought steel assembly with top and bottom rod adjustors. Adjustment accessible through center case after installation.
Top & Bottom Latch Case		4-1/2″ × 2-1/8″ × 1-1/2″ (114mm × 54mm × 38mm).
Center Case Latchbolt		Stainless Steel, deadlocking, 3/4″ (19mm) throw.
Top Latchbolt		Stainless steel, Pullman type deadlocking, 5/8″ (16mm) throw.
Bottom Latchbolt		Stainless steel, Pullman type deadlocking, independent action 5/8″ (16mm) throw. Round slide bolt optional.
Fire Bolt		Available for door openings up to 8′ (2438mm) wide × 10′ (3048mm) high. Specify suffix “LBR”.
Electrical Functions		Can be interfaced with building security systems:
– AL Alarm Exit		√
– DE Delayed Egress Device		√
– ELR Electric Latch Retraction		√
– LM Latchbolt Monitoring		√
– RX Request to Exit		√
– SS Signal Switch		√
– E Electric Mortise Lock
Dogging		NOT available on fire exit hardware. Flat/hex key dogging standard. Dogging options available for LD, CD, ED (ELR).
Strikes
– Panic
— Top		203/106 (roller type)
— Middle
— Bottom		227
– Fire
— Top		108 (roller type)
— Middle
— Bottom		227F
Cylinders		NOT furnished standard, specify when required.
Trim		The device and trim are sold separately, easy to mix and match.
Handing		500 Series Trim field reversible. Device non-handed. Specify handing for 400 Series trim when ordering.
Fasteners		Machine screws and wood screws are furnished standard.
Sex Bolts (SNB)		Required when used with wood, composite or non-reinforced hollow metal doors.
