Manual Flush Bolts. Controls.

Switching the lever/snib upward to unlock, downward to lock; You now have access control of the inactive door in your fingers.

Manual Flush Bolts

ANSI Grade 1 Door Hardware

Pivot lever type

Slider snib type

Download

Pivot lever type

Metal door

Klacci FB Series Flush Bolts Top Bolt FB9510T

FB9530

Top or Bottom Bolts

Up to 8′ x 10′ Metal Door Pairs.
UL Listed 3 Hour Fire Rating.

Wood door

FB9531

Top or Bottom Bolts

Up to 8′ x 10′ Wood Door Pairs.
UL Listed 1-1/2 Hour Fire Rating.

Specifications
Finishes
Dimensions
Strikes

Certification / Compliance	ANSI/BHMA A156.16 Grade 1. Conforms to ANSI/BHMA 156.16, L04251, L04261.
Features	Ease of installation. Non-handed.
Doors & Preparations	Fits standard ANSI/BHMA A156.115 (A115.4). Fits standard ANSI/BHMA A156.115W (A115.W5).
Top and Bottom Bolts	Bolts can be vertically adjusted up to 1″ for floor variance or frame conditions. 3/4″ bolt throw and 3/4″ backset. Bolt tip is 1/2″ diameter.
Strike	95-2708 strike standard. 95-2705 or 95-2706 dust proof strike available.
Standard Rod Length	12″ standard rod length measured from the center of the flush bolt body to the bolt tip. Optional 18″,24″,36″ and 48″ rod lengths available for top bolt only on non-fire rated openings.

A wide selection of finishes are available to match with your door and other hardware.

	ANSI/BHMA	US
Polished Brass	605	3
Satin Brass	606	3
Polished Bronze	611	9
Satin Bronze	612	10
Dark Oxidized Satin Bronze	613	10B
Polished Chrome	625	26
Satin Chrome	626	26D
Satin Stainless Steel	630	32D

Klacci FB Series Manual Flush Bolts Pivot Lever type Dimensions

Certification / Compliance	Conforms to ANSI/BHMA 156.16, L04011, L04021.
Features	Spring-loaded plunger returns to floor or threshold level anytime the Flush Bolt is retracted, removing the need of cleaning standard floor strikes.

Standard Strikes

P/N. 95-2708

Standard furnished for Manual Flush Bolt
15/16” Wide x 2-1/4” Long x 1/16” Thick

Dust Proof Strikes (Optional)

P/N. 95-2705

Body Size: 1-1/8” Diameter x 2-1/8” Deep

P/N. 95-2706

Body Size: 1-1/8” Diameter x 2-1/8” Deep
Face Plate Size: 1-5/8” Wide x 3-1/2” Long x 3/32” Thick

Slider snib type

Klacci FB Series Flush Bolts Top Bolt FB9511T

FB95410

Top or Bottom Bolts

Bolts

1″ bolt throw.
1/2″ backset.
Bolt tip is 1/2″ diameter.

Strike

95-2707 Strike standard.

FB95411

Top or Bottom Bolts

Bolts

3/4″ bolt throw.
1/2″ backset.
Bolt tip is 5/16″ diameter.

Strike

95-2709 Strike standard.

Specifications
Finishes
Dimensions
Strikes

Certification / Compliance

ANSI/BHMA A156.16 Grade 1.

Conforms to ANSI/BHMA 156.16, L04201.

Features

Position holding for bolt projection and retraction.

Non-handed.

A wide selection of finishes are available to match with your door and other hardware.

	ANSI/BHMA	US
Polished Brass	605	3
Satin Brass	606	3
Polished Bronze	611	9
Satin Bronze	612	10
Dark Oxidized Satin Bronze	613	10B
Polished Chrome	625	26
Satin Chrome	626	26D
Satin Stainless Steel	630	32D

Klacci FB Series Manual Flush Bolts Slider snib type Dimensions

Certification / Compliance	Conforms to ANSI/BHMA 156.16, L04011, L04021.
Features	Spring-loaded plunger returns to floor or threshold level anytime the Flush Bolt is retracted, removing the need of cleaning standard floor strikes.
