Klacci M系列特殊安全門鎖

M系列特殊安全門鎖

美國國家標準一級 Extra Heavy Duty

When a safe environment is needed

A lock is thought to be safe when it prevents forced intrusion. But is that the only risk we may encounter?

In recent years, suicide rates have increased alarmingly, among which ligature strangulation is one of the most common cases of self-inflicted injury. This typically occurs in buildings such as detention centers, hospitals, mental health centers, where mere constant monitoring is insufficient to prevent disasters to happen.

Klacci’s Anti-ligature Solutions provide the perfect hardware to prevent ligature attachment and self-harm, thus ensuring a risk-free environment.

產品特點

M Series Anti-Ligature Solutions have been designed to meet the strictest of safety requirements that Health Facilities need.

Our conical lock designs with sloped surface prevent ligature attachment, thus providing a safer environment. Complying with ANSI/BHMA A156.13 testing standard requirements, the lever handle design includes a clutch function, increasing the lock’s durability as well as the overall safety.

Trim type can be chosen between Lever and Knob design. The application of thru-bolt fastening adds additional strength.

Surpassing the strictest of requirements

As part of the world-renowned I-TEK Company, Klacci has not only inherited the expertise of 50 years of lock manufacturing, but also the expectation to provide the highest quality products.

Klacci’s Anti-ligature Solutions have gone through meticulous designs and improvements, and have been tested and certified to ANSI/BHMA A156.13 and ADA compliance, offering quality guaranteed products to our customers.

When choosing Klacci, you may rest assured that your doors are safe and secure.


認證
  • ANSI/BHMA A156.13 Series 1000, Grade 1 operational and security.

  • UL Listed for 3-Hour fire rating.
挖門孔
  • Conforms to ANSI A115.1, through bolted installation.
鎖匣尺寸
  • 4-5/16″ x 6″ x 1″ (110mm x 152mm x 25mm)。
Armor front
  • 1-1/4″ x 8″ x 7/32″ (32mm x 203mm x 5mm) Standard, 1-1/16″ x 8″ x 7/32″ (27mm x 203mm x 5mm) optional。
門距
  • 2-3/4″ (70mm) only.
適用門厚
  • 1-3/8″ (35mm) ~ 2-1/2″ (64mm) 鐵門。

  • 1-3/4″ (45mm) ~ 2-1/2″ (64mm) 木門。
Beveled Doors
  • Self-adjusting case.
軸心距離
  • 鎖芯與軸心距離為3-5/8″ (92mm)。 2-7/16″ (62mm) center thumbturn to spindle.
  • 98 mm available upon request.
輔助栓
  • 1″ (25mm) throw, stainless steel.
門栓
  • 長3/4″ (19mm)不鏽鋼防摩擦鎖舌。
Deadlocking Bar
  • 無方向性,不鏽鋼。
Case Handing
  • Field reversible without removing case.
Through Bolts
  • Through-bolted trim self-aligned with lock case.
擋板
  • Curved lip is non-handed. Custom lip lengths at 1/8″ (3mm) increments available.
轉動器
  • Breakable to prevent the lock case from unlocking or being damaged.
鎖芯
  • 6-pin standard, with two nickel silver keys, “C” keyway. Can be masterkeyed or grand masterkeyed. Construction key system available.
8字形可卸式鎖芯
  • 六珠或七珠實心銅彈子鎖芯, 可互換Best® 及Falcon® 鎖芯。
扣件/安全帶
  • Concealed under the escutcheon.
Function Code Number詳細內容 ANSI/BHMA
無輔助栓
  • Caution : Double cylinder locks on residences and any door in any structure which is used for egress are a life safety hazard in times of emergency and their use is not recommended. Installation should be in accordance with existing codes only.
Function Code Number詳細內容 ANSI/BHMA
有輔助栓
  • Caution : Double cylinder locks on residences and any door in any structure which is used for egress are a life safety hazard in times of emergency and their use is not recommended. Installation should be in accordance with existing codes only.

Made of brass or stainless steel, these trims are designed with elegance. The sloped profile prevents ligature attachment on the horizontal surface. Lever or knob handle options are available in standard or clutch (free turning) functions.

可以使用可選的抗菌塗層。特殊配方可防止細菌在門把手錶面生長。適用於高衛生要求的場所中的高流量應用。要訂購,請添加前綴AC。

Klacci M系列特殊安全門鎖 ALT 水平把手Klacci M系列特殊安全門鎖 ALTB 握把把手
ALT 水平ALTB 握把
Klacci M系列特殊安全門鎖 旋鈕Klacci M系列特殊安全門鎖 鎖心防護套
Turn鎖心防護套

We offer a full and complete line of spacer rings, cylinder guards and spring washers, as well as a wide selection of cam types to fulfill the requirements of most applications. Standard mortise cylinders are furnished in 5 or 6 pin configurations. Interchangeable core mortise cylinders are also available in 6 or 7 pin configurations, where increased security is achieved by quick change of keying.

圖示Face長度
1-1/8″1-1/4″1-3/8″1-1/2″1-1/2″1-3/4″1-7/8″
Klacci 匣式門鎖 鎖芯 外露 標準外露
標準
441-102441-103441-103441-103441-106441-106441-108
Klacci 匣式門鎖 鎖芯 隱藏 標準隱藏
標準
441-402441-403441-404441-405441-406441-407441-408
Klacci 匣式門鎖 鎖芯 外露 8字形可卸式鎖芯外露
8字形可卸式鎖芯
N/A442-601442-701442-702N/AN/AN/A
Klacci 匣式門鎖 鎖芯 隱藏 8字形可卸式鎖芯隱藏
8字形可卸式鎖芯
N/A442-601442-601442-902N/AN/AN/A

Additional cams are available for our mortise cylinder to operate in other manufacturers’ mortise locks.

Klacci 匣式門鎖 Cylinder Cam 440-0702Klacci 匣式門鎖 Cylinder Cam 440-0703Klacci 匣式門鎖 Cylinder Cam 440-0704Klacci 匣式門鎖 Cylinder Cam 440-0801Klacci 匣式門鎖 Cylinder Cam 440-0705Klacci 匣式門鎖 Cylinder Cam 440-0706Klacci 匣式門鎖 Cylinder Cam 440-0708Klacci 匣式門鎖 Cylinder Cam 440-0709
440-0702440-0703440-0704440-0801440-0705440-0706440-0708440-0709

We offer two types of cylinder guards to work with sectional trim for different door ranges and various cylinder lengths. Specify part number when ordering.

Klacci 匣式門鎖 Armor Front (Faceplates) Square Corner

Square Corner

Klacci 匣式門鎖 Armor Front (Faceplates) Square Corner

1/4″ Radius Corner

Square Corner1/4″ Radius Corner詳細內容
1-1/4″
(32mm)
1-1/16″
(27mm)
1-1/4″
(32mm)
1-1/16″
(27mm)
528-711528-731528-721528-741門栓 × Aux. 門栓 × 輔助栓
528-712528-732528-722528-742門栓 × Aux. 門栓
528-713528-733528-723528-743門栓 × 輔助栓
528-714528-734528-724528-744門栓
528-715528-735528-725528-745空白
528-716528-736528-726528-746輔助栓

Non-handed, made of brass, bronze or stainless steel. Available with square corner or 1/4″ radius corner.

Klacci 匣式門鎖 擋板 527-611 Square Corner

527-611

Square Corner

Klacci 匣式門鎖 擋板 527-611 Square Corner

527-631

1/4″ Radius Corner

Klacci 匣式門鎖 擋板 527-611 Square Corner

527-610

Square Corner

Klacci 匣式門鎖 擋板 527-611 Square Corner

527-630

1/4″ Radius Corner

集塵盒是鐵製, 已提供不需額外付費。

Klacci 匣式門鎖 擋板 527-611 Square Corner

552-312

集塵盒

有多種表面顏色選擇可搭配您的門扇和五金配件。

顏色ANSI/BHMAUS
Klacci 表面顏色 605 亮面黃銅亮面黃銅6053
Klacci 表面顏色 606 砂面黃銅砂面黃銅6063
Klacci 表面顏色 611 亮面丹銅亮面丹銅6119
Klacci 表面顏色 612 砂面丹銅砂面丹銅61210
Klacci 表面顏色 613 黑61310B
Klacci 表面顏色 625 亮鉻亮鉻62526
Klacci 表面顏色 626 霧鉻霧鉻62626D
Klacci 表面顏色 630 砂面不鏽鋼砂面不鏽鋼63032D
